Bildsynthese
Path Tracing

struct RayPayloadType {
  vec3 radiance;
  vec3 nextRayOrigin;
  vec3 nextRayDirection;
  vec3 nextFactor;
  int level;
}; // type of the "payload" variable

...

void main() { /**** RAY GENERATION SHADER ****/

  // compute random pixel offset
  vec2 pixelOffset = hammersley(uint(frameID), uint(frameSize));

  // compute the texture coordinate for the output image in range [0.0, 1.0]
  vec2 texCoord = (vec2(gl_LaunchIDEXT.xy) + pixelOffset) / vec2(gl_LaunchSizeEXT.xy);

  // camera parameter
  float aspect = float(gl_LaunchSizeEXT.x) / float(gl_LaunchSizeEXT.y);
  vec3 rayOrigin = camPos;
  vec3 rayDirection = getCameraRayLookAt(30.0, aspect, camPos, camLookAt, camUp, texCoord);

  uint rayFlags = gl_RayFlagsNoneEXT; // no ray flags
  float rayMin = 0.001; // minimum ray distance for a hit
  float rayMax = 10000.0; // maximum ray distance for a hit
  uint cullMask = 0xFFu; // no culling

  // init ray and payload
  payload.nextRayOrigin = rayOrigin;
  payload.nextRayDirection = rayDirection;
  payload.nextFactor = vec3(1.0);
  vec3 contribution = vec3(1.0);
  vec3 color = vec3(0.0, 0.0, 0.0);
  int level = 0;
  const int maxLevel = 5;

  // shot rays
  while(length(payload.nextRayDirection) > 0.1 &&
        level < maxLevel && length(contribution) > 0.001) {
    payload.level = level;
    // Submitting the camera ray to the acceleration structure traversal.
    // The last parameter is the index of the "payload" variable (always 0)
    traceRayEXT(topLevelAS, rayFlags, cullMask, 0u, 0u, 0u,
            payload.nextRayOrigin, rayMin, payload.nextRayDirection, rayMax, 0);

    color += contribution * payload.radiance;
    contribution *= payload.nextFactor;
    level++;
  }

  if(frameID == 0) {
    gsnSetPixel(vec4(color, 1.0));
  } else {
    vec3 previousAverage = gsnGetPreviousPixel().rgb;
    previousAverage = pow(previousAverage, vec3(2.2)); // inverse gamma correction
    vec3 newAverage = (previousAverage.rgb * float(frameID) + color) / float(frameID + 1);
    newAverage = pow(newAverage, vec3(1.0 / 2.2)); // gamma correction
    gsnSetPixel(vec4(newAverage, 1.0));
  }
}

void  main() { /**** CLOSEST-HIT SHADER ****/

  // get mesh vertex data in object space
  vec3 p0, p1, p2;
  gsnGetPositions(gl_InstanceID, gl_PrimitiveID, p0, p1, p2);
  vec3 n0, n1, n2;
  gsnGetNormals(gl_InstanceID, gl_PrimitiveID, n0, n1, n2);
  vec2 t0, t1, t2;
  gsnGetTexCoords(gl_InstanceID, gl_PrimitiveID, t0, t1, t2);

  // interpolate with barycentric coordinate
  vec3 barys = vec3(1.0f - baryCoord.x - baryCoord.y, baryCoord.x, baryCoord.y);
  vec3 localNormal = normalize(n0 * barys.x + n1 * barys.y + n2 * barys.z);
  vec3 localPosition = p0 * barys.x + p1 * barys.y + p2 * barys.z;
  vec2 texCoords = t0 * barys.x + t1 * barys.y + t2 * barys.z;

  // transform to world space
  mat3 normalMat;
  gsnGetNormal3x3Matrix(gl_InstanceID, normalMat);
  vec3 normal = normalize(normalMat * localNormal);
  vec3 position = gl_ObjectToWorldEXT * vec4(localPosition, 1.0);

  // assign materials
  // Cornell Box
  vec3 baseColor = cornellWhite;
  vec3 emission = vec3(0.0);
  if(gl_InstanceID == 2 && texCoords.x < 0.25) {
    baseColor = cornellRed;
  }
  if(gl_InstanceID == 2 && texCoords.x >= 0.5 && texCoords.x < 0.75) {
    baseColor = cornellGreen;
  }
  // light sphere
  if(gl_InstanceID == 1) {
    baseColor = vec3(0.0);
    emission = vec3(20.0);
  }

  // different random value for each pixel, each level, and each frame
  vec3 random = random_pcg3d(uvec3(gl_LaunchIDEXT.xy, frameID + payload.level));

  // uniform sampling of hemisphere
  float theta = 0.5 * PI * random.y;
  float phi = 2.0 * PI * random.x;

  payload.radiance = emission;

  // sampled indirect diffuse direction in normal space
  vec3 localDiffuseDir = vec3(sin(theta) * cos(phi), sin(theta) * sin(phi), cos(theta));
  vec3 diffuseDir = getNormalSpace(normal) * localDiffuseDir;
  payload.nextRayOrigin = position;
  payload.nextRayDirection = diffuseDir;
  payload.nextFactor = baseColor * PI * cos(theta) * sin(theta);
}

void main() { /**** MISS SHADER ****/
  // set color to black
  payload.radiance = vec3(0.0, 0.0, 0.0);
  // no more reflections
  payload.nextRayOrigin = vec3(0.0, 0.0, 0.0);
  payload.nextRayDirection = vec3(0.0, 0.0, 0.0);
}
